Static Mixer, Static Mixing Technology

Static mixers help to get the desired mixing of two or more components without moving of equipment. These mixers are also specialized for the continuous mixing of components with perfect-mannered mixing quality. The compact structure of the static mixer mixes the streams of fluids into housing and pipelines. Adequate mixing in such a compact area can be obtained by inserting a static mixer only. It differentiates itself with its stable and fixed nature, unlike traditional mixers. Here we offer optimized blending technology for fluids as well as gasses with less energy consumption. Our efficient mixers are fully developed and manufactured to only satisfy and justify industrial needs.

S-Cube Mass Transfer India provides Static Mixing Technology widely used in the fluid processing industry. We are one of the best Static Mixer suppliers in Pune, India.

Working Principle of Static Mixer

Static mixing assure that mixing can be achieved in short pipe length and in motionless operation. The efficiency of a static mixer depends on the angular arrangement of elements. Mixing elements are serially arranged one after another to get a homogeneously mixed outlet throughout. Various angles mixing elements divide and Recombine the streams through the mixer to achieve the required homogeneous mixture. Process requirements and specific properties such as density, the viscosity of fluid stream, and degree of mixing of mixture are the factors that decide the number of mixing elements required in a mixer.

Benefits of Static Mixer

Direct molding of material into mixing elements gives efficient mixing without energy consumption.
Proper distribution of fluid streams, and additives into short pipe sections can be achieved in a very short time.
Most consistent type of mixer in the segment regarding viscosity, color, and texture of the product outlet.
Easy and customizable to handle. Quick changes in mixture or stream ratio can be done accordingly.
Accurate shaping and sizing of the mixer provided. Need not be modified or reevaluated, unlike large mixers.
Compatible with all types of industrial applications.

Process Applications

A wide variety of process applications take advantage of static mixing technology including:

Static Mixer

High Efficiency SMX element

SMV Element

Specifications of Static Mixers

Laminar Flow

High Viscosity Mixing
High – Low Viscosity Mixing
Heat Transfer Enhancement

Turbulent Turbulent

Low Viscosity Liquids Mixing
Gas Mixing
Dispersion of Immiscible Liquids
Gas-Liquid Contacting

Industrial Applications

Almost every processing industry uses static mixers for its particular applications. The applications of static mixer in various industries has been categorized as,

Chemical Industry

Distribution of immiscible liquids in various washing and extraction operations
Mixing gases with the air in front of catalytic reactors such as in the Nitric Acid production process.
Dissolving gases into liquids such as NH3, SO2, Cl2
Mixing Reactive materials in short length/Space
Heating and Cooling of the viscous materials

Food Industry

Blending of fruit juice concentrates
Adding CO2gas to fruit juices, wine, beer, etc.
Dilute concentrates
Heating and cooling chocolate

Water & Wastewater Treatment

Controlling pH of waste water with acids/bases
Dilution of Flocculants and addition of it to waste water
For Dissolving purpose of CO2, O2, Cl2 and Ozone into water
For Mixing ground and surface waters
Aerated drinking water processes

Oil, Gas & Petrochemicals

Mixing of crude oil to provide uniform and homogeneous feed to refinery
For contacting crude oil with water to get optimized desalted performance
Adding additives into gasoline, lubricating oils, fuel oil
Mixing of steam with methane for feeding into reformer
For contacting used lubricating oils with sulfuric acid for treatment of waste oil

Other Industries

Natural Gas Processing
Pharmaceuticals
Pulp & Paper Processing
Cosmetics & Detergents
Potable Water Treatment
Power Plants
Energy
Catalyst Manufacture and Catalytic Reactors
Pollution Control
Minerals & Ore Processing
Vegetable Oil Processing
Reverse Osmosis Feed Pretreatment
Scrub Noxious Gases with caustic
